Features:

• Integrated point laser for incline measurement up to a distance of 30 m
• Strong magnets and two straps for securely fastening the instrument to workpieces
• Incline mechanism for fine adjustment on uneven surfaces
• Any value can be set as alternative 0°
• Angles can be adjusted manually to enable easy transfer
• Audio signal guides the user to the desired angle without having to look at the display
• Units of measure can be switched
• Automatically rotating display for better readability

Specifications:

• Length: 600mm
• Measurement range: 0 - 360° (4 x 90°)
• Electronics measurement accuracy:
• 0°/90°: ±0.05°
• 1°-89°: ±0.1°
• Laser working range: 30m
• Laser type: 635Nm, <1mW
• Laser class: II
• Levelling accuracy of laser: ±0.5
• Units of measurement: °, %, mm/m
• Tripod thread: 1/4"
• Dimensions (L x W x H): 618mm x 27mm x 59mm
• Weight: 0.7kg

Warranty:

• 3 Years Warranty via registration Covered By Bosch Australia
